New Studer OnAir 2500 Modulo Variant Now Available

April 15, 2009

REGENSDORF, Switzerland – Studer has introduced a new modular version of the successful OnAir 2500 broadcast console for installation in custom studio furniture.



The new model OnAir 2500 Modulo has separate modules for fader bays and master section, along with a rack-mountable mainframe which houses the power supply and host processing. These modules can be recessed into a desktop for a clean installation with all cables integrated within the furniture and the mainframe hidden appropriately.



The OnAir 2500 Modulo was introduced in response to demand from the market for a recessable console.



In Switzerland, a custom version of the OnAir 2500 console was built into a stunning desk at Radio 105 / Radio Monte Carlo, which changes color when it is on-air and the mics are live whether on-air or off-air.



The OnAir 2500 digital all-in-one broadcast console utilizes well-established software technology derived from the highly acclaimed OnAir 3000 console to deliver a new standard in ease of use for radio broadcast.



The fader strips include a graphical OLED (Organic LED) screen, which contains a channel label, level and gain reduction meter and parameter readouts, adjustable via a rotary encoder and two push buttons below the display. OLED screens have a much wider viewing angle than LCDs and have much higher definition, so operators can immediately see information much more clearly.



The large TFT color touch screen uses Studer’s patented Touch’n’Action system, where only the most important functions have hardware control elements in the channel strip, making the operation of the console very simple and stress-free.



The touch screen can also display all the relevant settings and configurations for each channel in addition to the OLED displays. A simple touch on one of the eight small channel pushbuttons, e.g. equalizer, dynamics, AUX send, immediately opens the corresponding page on the main screen, allowing quick and easy adjustment.



The most important functions are just one finger stroke away, accessible virtually instantly – vital in a hectic, live on-air situation. The user interface is designed in the similar symbolic language as the highly regarded Vistonics™ system and adjusted in a very flat hierarchy without the use of multi-level menus.





The OnAir 2500 Series provides the user with a large number of inputs and outputs in many standard signal formats. In addition to interfaces on XLR and SUB-D outlets (microphone inputs, headphone outputs, Line and AES I/Os), the internal audio system also offers interfaces to digital multi-channel formats such as MADI, ADAT and IEEE 1394 Firewire.



Three fixed-frame configurations with 12, 18 and 24 faders are also available, both variants having motorized channel faders available as an option. Large illuminated pushbuttons allow access to the main channel functions, editable via the 12” color TFT touch screen.



Integration with Studer’s Call Management System (CMS) is seamless, which allows caller names to be dynamically displayed as fader channel labels, while further integration of radio automation systems is easily accomplished using the Monitora protocol via serial interface or TCP/IP.



The OnAir 2500 can also support I/O Sharing via Studer’s proprietary networked technology STUDER RELINK, allowing the OnAir 2500 to share audio signals with other Studer consoles including the OnAir 3000 and Studer Vista Series.



For such a compact package, the Studer OnAir 2500 offers unrivalled flexibility and operational ease.
